EcoFlow Smart Home Panel 2
Intelligent subpanel: outage protection and savings in one EcoFlow Smart Home Panel 2!
The EcoFlow Smart Home Panel 2 is the center of your whole-home backup system. Compatible with EcoFlow DELTA Pro Ultra, batteries, generators and solar panels, complete with auto-switchover for instant backup.
Circuit control allows for more extended backup and prepares your system for outages with an hourly weather assessment.
Customize your energy consumption based on TOU (Time Of Use) peak and off-peak rates and the amount of solar energy your home generates.
EcoFlow Smart Home Panel 2 is the hub of the powerful EcoFlow DELTA Pro Ultra that allows you to get the full potential out of your energy system. Connect your home circuits with up to 3 plug-and-play inverters and 15 stackable 6kWh batteries, it not only takes care of your backup for even longer but allows you to control and run every single household appliance. EcoFlow Smart Home Panel 2 is future-proofed to work with our next-gen power solutions, and it works with EcoFlow DELTA Pro¹, too.
EcoFlow Smart Home Panel 2 can manage your energy from various sources, including solar and gas. With the sun's rays, brighten your home with cost-effective green energy and dramatically reduce your electricity expenses.
When the weather turns stormy and you're all out of sunshine, a seamless connection to any 3-12kW portable gas generator ensures your home stays energized without a hitch.
The nights of fumbling for a flashlight are over.
When an outage hits, there's no need to brave the dark, cold night to switch to your backup manually. EcoFlow Smart Home Panel 2's automatic switchover feature ensures your home remains powered even when you're away. Forget spoiled food and damaged appliances. Embrace uninterrupted power so that life never stops.
Black-out Proof Energy
EcoFlow Smart Home Panel 2 ensures your home is blackout-proof with ample energy at all times. Even when an outage lingers on, it's business as usual.
Key Features: EcoFlow Smart Home Panel 2
- Can accommodate up to 3 Delta Pro Ultra inverter/battery stacks
- Innovative Design for a Hassle-Free Experience
- Monitor operation via PowerInsight console and/or the EcoFlow app
- Self-Power Mode
- 20-ms Auto-Switchover
- Compatible with Solar and Gas Generators
- Connects your EcoFlow Delta Pro Ultra home battery backup system with your Main electrical panel
- Smart Energy Management
- Easy installation
- NEMA 3R weatherproofed enclosure
- 10-year warranty
What's In The Box:
- 1 x EcoFlow Smart Home Panel 2 (glass door and deadfront cover packaged separately)
- 1 x Marking-off Template
- 1 x EcoFlow Power Input/Output Cable
Documents: EcoFlow Smart Home Panel 2
Video: EcoFlow Smart Home Panel 2
FAQ
FAQ
How does the Power Hub communicate the voltage to the Smart Distribution panel?
There are two included RJ45 network cables included in a Independence Power Kit. One that connects the Power Hub directly to the Smart AC/DC Distribution Panel; a second one to connect the Power Hub to the Power Kit Console.
What is the operating temperature range of the Power Kit Console?
The information as stated in the user manual is below: -20C to 50C (-4F to 122F). This is the operating temperature range for all
Power Kit components.
What is considered a standard alternator input scenario and what is else is allowed involving alternator charging with EcoFlow Power Kits?
All 3x PV/ALT input ports can be used as alternator charging ports. The first ATL-IN input port can allow 70A max and 1600W input max, meaning that if you draw from 12V alternator you can only get 13.6V x 70A = 952W which is almost 1000 (it will fluctuate between 950W and 1000W). If a 48V alternator is connected to port 1, then an estimated 54V x 29.6A = 1600W is expected. The 2nd and 3rd ALT-IN input ports are both 30A max and 1600W max. If you connect a 12V alternator to these ports, an estimated 13.6V x 30A = 408W each is expected. If you connect a 48V alternator to ALT-IN 2 or 3 ports, an estimated 54V x 29.6A = 1600W each is expected. If you connect a 12V alternator on all 3 ALT-IN input ports, an estimated 952W + 408W + 408W = 1768W (if your 12V alternator can deliver 70A + 30A + 30A = 130A) is expected. If you use 48V alterantor on all 3 ports, an estimated 1600W + 1600W + 1600W = 4800W input is expected.
What type of shore power inlet is recommended for an EcoFlow Power Kit?
The Power Kit allows up to 30A input, so we recommend 30amps max. 30A to 15A converters are available if your enegy consumption needs are not high. Furrion is a tested and trusted brand that has worked perfectly with an EcoFlow Power Kit.
